CAD Design Services
US Flat Pattern has designers, mechanical engineers and professional engineers supporting all facets of offsite CAD support.
We have experts available in automotive, aerospace, medical and consumer product fields.
CAD Software Platforms
-
Catia V6, V5, V4
- Installed versions: Catia V5-6R2016, V5-6R2015, V5-6R2014, V5-6R2012, V5R24, V5R23, V5R22, V5R21, V5R20, V5R19, V5R18, V5R17, V5R16, V5R14, V5R7, V4 (all releases).
-
Unigraphics
NX
- Installed versions: NX11, NX10, NX9, NX8.5, NX8, NX7.5
- Available versions: All
- Solid Edge
- Legacy versions: V21-V14, V7
- SolidWorks
- Installed versions: 2015, 2014, 2007
- Available versions: All
- Neutral formats
- Dxf, dwg, step203, step214, parasolid, iges 2D, iges 3D, and also 3D pdf. With 3D pdf you can pan, zoom, rotate and measure your parts via Adobe Reader (no special software required).
- Complete CAD export and import list
here
