Flat pattern services
Flat patterns, flat blanks and Wire harness formboard layout services.
Outputs to any CAD format plus 2D and 3D pdf as applicable.
Highlighted applications
- Sheet metal flat pattern services
- Standard sheet metal flat patterns with bend directions, bend angles, and bend lines specified.
- Progressive die flat patterns for body structural components.
- Die cut flat patterns as solid bodies or curve sets in the X,Y plane.
- 3D flat patterns for rubber part tooling
- Contoured sealing gaskets
- Windshield and access cover gaskets
- Die cut flat patterns.
- Formboard layouts. Wire harness flat pattern services.
- Our formboard layouts are most excellent. Build your wire harnesses the easy way, right on top of our mylar layouts. We deliver full scale layouts at roll stock width of 36". We include connector callouts, key locations, key orientations, segment lengths, wire diameters and whatever information you need included.
- Unfolded shapes
- Class "A" surface flat patterns
- Sheet metal flat patterns
- Automotive cloth and leather flat patterns
- Garment industry Cloth flat patterns with weave counts
